ARTIX-7 FPGA Development Board AX7A200 User Manual
PIN43
B16_L5_N
PIN45
B16_L7_P
PIN47
B16_L7_N
PIN49
GND
PIN51
B16_L9_P
PIN53
B16_L9_N
PIN55
B16_L11_P
PIN57
B16_L11_N
PIN59
GND
PIN61
B16_L13_P
PIN63
B16_L13_N
PIN65
B16_L15_P
PIN67
B16_L15_N
PIN69
GND
PIN71
B16_L17_P
PIN73
B16_L17_N
PIN75
B16_L19_P
PIN77
B16_L19_N
PIN79
NC
Figure 2-9-4: Board to Board Connectors CON4 on the Core Board
Part 2.10: Power Supply
The AC7A200 FPGA core board is powered by DC5V via carrier board,
and it is powered by the Mini USB interface when it is used alone.
careful not to supply power by the Mini USB and the carrier board at the same
time to avoid damage.
in Figure 2-10-1.
