ARTIX-7 FPGA Development Board AX7A200 User Manual
The figure 3-11-2 detailed the J11 expansion port on the carrier board. The
Pin1 and Pin2 of the expansion port are already marked on the board.
Figure 3-11-2: Expansion header J11 on the Carrier Board
J11 Expansion Header Pin Assignment
Pin Number
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
51 / 59
FPGA Pin Pin Number
GND
G21
C22
F19
D20
A18
B20
F18
E19
C18
B17
D17
A15
B15
A13
E16
C14
F16
GND
+3.3V
Amazon Store:
Sales Email: rachel.zhou@aithtech.com
FPGA Pin
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
+3.3V
https://www.amazon.com/alinx
+5V
G22
B22
F20
C20
A19
A20
E18
D19
C19
B18
C17
A16
B16
A14
D16
C15
E17
GND
