7 WEB Interface
step 2 After editing the IEC104 forwarding point table, click Export→IEC104 CFG in the menu bar,
and the prompt window will pop up. Convert the excel file into .xml file, where the .xml file
and the excel file are in the same path.
step 3 Click Add, to enter the Advanced Settings interface.
step 4 Enter Domain and Peer Port, and select Remote Signaling Measuring Point Type,
Remote Signaling Time Mark, and Upload with a Change.
step 5 Click configuration
step 6 Click Save.
- - End

7.10.8 MODBUS

Configure the MODBUS forwarding service for the Logger1000 on this interface.
7.10.8.1 Server Mode
In the Server Mode, Logger1000 is used as a Server and connected to PC server through
Modbus TCP protocol to implement data transmission and instruction delivery.
step 1 Click System→Transfer Configuration→MODBUS to enter the corresponding interface.
step 2 For the white list setting, refer to
- - End
7.10.8.2 Client Mode
In the Client Mode, Logger1000 is used a Client and connected to PC server through
Modbus TCP protocol to implement data transmission and instruction delivery.
step 1 Click System→Transfer Configuration→MODBUS to enter the Server tab by default.
step 2 Click Client to enter the corresponding tab.
step 3 Click Add to enter the Advanced Settings interface.
step 4 Enter Domain and Peer Port and click Save.
- - End
7.10.8.3 RTU Mode
In the RTU mode, Logger1000 is connected to PC server through Modbus RTU protocol to
implement data transmission and instruction delivery.
step 1 Click System→Transfer Configuration→MODBUS to enter the "Server" tab by default.
step 2 Click RTU to enter the corresponding tab.
step 3 Select serial port and enter delay time.
step 4 Click .
54
to import .xml file.
"7.10.7.1 White list setting".
