7 WEB Interface
Set the system time when using the Logger1000 for the first time.

7.10.6 iSolarCloud

step 1 Click System→Transfer Configuration to enter the corresponding interface.
step 2 Click the button
- - End
The default iSolarCloud station is Chinese Server. Users in mainland China
select Chinese Server, users in Europe select European Server,users in
Australia select Australian Server,and users in other regions select the
International Server.
To ensure that the Logger1000 functions normally, the firewall network needs to open the
following access rights.
iSolarCloud server
Chinese Server
European Server
Australian Server
International Server

7.10.7 IEC104

Configure the IEC104 forwarding service for the Logger1000 on this interface.
• Server Mode
In the server mode, Logger1000 is used as a Server and connected to PC server to
implement data transmission and instruction delivery.
Click System→Transfer Configuration→IEC104 to enter the corresponding interface.
The local port is 2404.
• Client Mode
In the client mode, Logger1000 is used as a Client and connected to PC server to
implement data transmission and instruction delivery.
step 1 Click System→Transfer Configuration→IEC104 to enter the "Server" tab by default.
50
to modify the forwarding configuration information of iSolarCloud.
Destination address
iot.isolarcloud.com
iot.isolarcloud.eu
auiot.isolarcloud.com
iot.isolarcloud.com.hk
User Manual
Destination port
• TCP : 19999
• TCP : 16668
• TCP : 8443
• TCP : 80
• TCP : 443
• UDP : 123
