Sungrow Logger1000B User Manual page 68

7 WEB Interface
7.10.10.4 Mobile network
Perform Mobile network setting on this interface.
step 1 Click System→Port Parameter→Mobile Network to enter the corresponding interface.
step 2 After modifying the APN, Username and Password, click
- - End
7.10.10.5 WiFi
Perform WiFi setting on this interface.
Client
Client refers to a case in which the Logger1000 connect to another hotspot or router via the
WLAN function.
Click System→Port Parameter→WiFi to enter the corresponding interface. Users will enter
the client mode by default, and the WLAN switch is closed.
Hotspot
Hotspot mode means that the Logger1000 is used as an hotspot, and the PC or mobile
phone can be connected to the Logger1000 via the WLAN function.
Click System→Port Parameter→WiFi to enter the corresponding interface. Click Hotspot
to enter the corresponding interface.
table 7-13 Description of hotspot parameter
Parameter
SSID
Security
Changing of the WLAN hotpot password requires reconnection of the WLAN.
7.10.10.6 AI
step 1 Click System→Port Parameter→AI to enter the corresponding interface.
step 2 Select an input type, set the lower limit and upper limit, and click the button
operation.
table 7-14 Description of AI parameter
Parameter
Voltage lower limit（V）
Voltage upper limit（V）
Current lower limit（mA）
Current upper limit（mA）
58
Description
Network name
Null: without password
WPA2: hotspot encrypted, password required
Default value
0
10
4
20
User Manual
to save the information.
to save the
Range
0 ~ 10
0 ~ 10
4 ~ 20
4 ~ 20
