User Manual
7.8.1.2 Export
step 1 Click Device→Device List to enter the corresponding interface.
step 2 Click the button
- - End
7.8.1.3 Import
step 1 Click Device→Device List to enter the corresponding interface.
step 2 Click the button
step 3 After the device list is exported, the user can modify device names in batch.
step 4 After the modification is completed, save the device list file in the .csv format.
step 5 Click the button
- - End
7.8.1.4 Add device
step 1 Click Device→Device List to enter the corresponding interface.
step 2 Click Add Device, select a Device Type in the pop-up window, and fill in the information
required.
- - End
7.8.1.5 Add the Third-party Meter (Import Files)
step 1 Click Device→Device List to enter the corresponding interface.
step 2 Click Add Device, select Meter option in the Device Type.
step 3 Select the port (COM1/COM2/COM3/NET) that the meter is actually connected to in the
Port.
step 4 Select Others option in the Device Model.
step 5 Select Import Files option in the Configuration Method.
step 6 Select the corresponding measuring point template in the "Configuration File". Or click the
icon to import the configuration file.
step 7 Enter the value of Beginning Address and the Quantity of Device, click Save.
Be aware of the number of device added in each port, the Beginning Address to
be entered should bigger than the device address existed if they are in the same
port.
- - End
to export the device list.
to export the device list.
to import the .csv file into the Web.
7 WEB Interface
41
