step 2 Click Client to enter the corresponding tab.
- - End
7.10.7.1 White list setting
When the option Enable White List is not selected, and the default IP address is "0.0.0.0",
any background devices with valid IP address can access the Logger1000.
When the option Enable White List is selected, and specified IP address is entered, only
the device with the specified IP address can access the Logger1000.
7.10.7.2 Generate Point Table
step 1 Turn on the switch of local port 2404.
step 2 Click Generate Point Table, and default IEC104 point table will be automatically imported
to configuration file.
- - End
7.10.7.3 Edit IEC104 Forwarding Point Table
step 1 Click Export of Configuration Tools to export the IEC104 forwarding point table.
step 2 Open the sheet Introduce of the IEC104 forwarding point table, where data of five types (-
telemetry, telesignalling, remote pulse, remote control, and remote regulating) are included.
table 7-5 Introduce tab parameters
Data Type
YC
YX
YM
YK
YT
step 3 Open the sheet Cfg Para of the IEC104 forwarding point table to view and set the
addresses of the five types of data. The addresses shown in the following table are default
ones and can be modified according to actual situation.
table 7-6 Cfg Para tab parameters
Data Type
Bngr Addr
step 4 Open the sheets such as inverter, Smart Energy Meter, Meteo Station, and Logger1000, to
set corresponding measuring point data.
YX YC
1 16385
Description
Telemetry
Telesignalling
Remote pulse
Remote control
Remote regulating
YM YK
15221 15271
7 WEB Interface
YT
15000
