User Manual
- - End
Serial Port is set to Forwarding Is Prohibited by default, in which case this port
can only be used to collect data. If the logger is connected to a third-party device
through a COM port for data forwarding, select the COM port in the drop-down list
of Serial Port. A maximum of two COM ports can be used for forwarding.

7.10.9 Third-party portal

Configure the third-party cloud forwarding service for the Logger1000 on this interface.
step 1 Click System→Transfer Configuration→Third-party Portal to enter the corresponding
interface.
step 2 Turn on the switch.
step 3 Click the button
step 4 Modify the configuration information and click Save.
Set the FTP path and name it as "/FTP server directory".
For example, for the name "/SUNGROW", / is the root directory, and SUNGROW
is the directory where data is stored on the FTP server.
- - End

7.10.10 Port Parameter

Set ports of the Logger1000 on this interface.
7.10.10.1 RS485
step 1 Click System→Port Parameter→RS485 to enter the corresponding interface.
step 2 Click to modify Baud Rate, Parity Bit, and Stop Bit.
step 3 Click Save to save the information.
- - End
When the Logger1000 is connected to a device via the serial port, the Baud Rate,
Parity Bit, and Stop Bit of the serial port should be the same as those set for the
connected device, so as to ensure normal communication between the
Logger1000 and the connected device. The baud rate is 9,600bps, stop bit is 1,
and there is no parity bit by default.If EyeW485 is enabled, set the baud rate of the
corresponding COM port to 115,200.
on the operation bar, so that an Advanced Setting window will pop up.
7 WEB Interface
55
