Ethernet Login; Web Main Interface - Sungrow Logger1000B User Manual

7 WEB Interface
User types include "general user" and "O&M user".
The general user can view basic information, real-time fault, and device
monitoring information of the Logger1000.
In addition to all permissions of the general user, the O&M user has the
permission to set and modify parameters of the Logger1000 and devices
connected to the Logger1000.
In the following, description is given by using the O&M permission as an example.
After login for the first time, it is recommended to change the password as soon as
possible. Click O&M user→Modify password to change the password.
With the login password forgotten, contact SUNGROW and provide the device S/
N as well as system time, to get the password.

7.2.2 Ethernet Login

step 1 The IP address of the PC connected to the Logger1000 is the same as that of the
Logger1000. The IP address is 12.12.12.X. For example, the IP address of the PC can be
set to 12.12.12.125, and the subnet mask is 255.255.255.0.
IP of Logger1000 is 12.12.12.12 by default, and subnet mask is 255.255.255.0.
step 2 Connect the Logger1000 to the PC via the Ethernet.
step 3 Enter the IP address 12.12.12.12 of the Logger1000 in the PC address bar to enter the
general user login interface.
step 4 Click the button Login in the upper right corner, enter the default password "pw1111", and
click Login, to enter the O&M user interface.
- - End
User types include "general user" and "O&M user".
Users of different types have different permissions.
7.3

Web Main Interface

When the "O&M user" logs into the Web for the first time, the "Help" window pops up. Follow
the prompts to perform operations such as time synchronization, device connection, and
forwarding configuration.
The Web main interface is as follows:
34
