User Manual
table 7-9 Description of parameter
Parameter
No.
Device Type
Com ID*
Collect ID*
Access ID*
Template Sheet
Reserved YX Addr
Reserved YC Addr
Reserved YM Addr
Reserved YK Addr
Reserved YT Addr
Note: Export the excel from the Device list interface and copy the data in the exported excel.
- - End
7.10.7.4 Import IEC104 forwarding point table
step 1 After editing the IEC104 forwarding point table, click Export→IEC104 CFG, so that a
prompt window pops up, and then convert the excel file into xml file. The xml file and the
excel file are at the same path.
step 2 Click the button
window, to import the xml file.
- - End
7.10.7.5 Add Peer Port Information
step 1 Configure point table, where reference can be made
Point Table".
figure 7-1 Device List tab parameters
Description
Sort devices, and only support moving the whole line for the
device type corresponds one-to-one to its parameters in the
same line
Device type
Number of COM port to which device connected,
corresponding to the port data of the "Device list" on the Web
interface
Collect device Modbus address, corresponding to
communication address of the "Device list" on the Web
interface
Background access address, corresponding to the forwarding
address of the "Device list" on the Web interface
Keep consistent with the that in the device sheet
Reserved telesignalling address
Reserved telemetry address
Reserved remote pulse address
Reserved remote control address
Reserved remote regulating address
on the operation bar, and then click the button on the pop-up
to"7.10.7.3 Edit IEC104 Forwarding
