Message Export - Sungrow Logger1000B User Manual

7 WEB Interface
• Users in Australia select Australian Server.
• Users in other regions select the International Server.
The remote maintenance address will change once the Logger1000 is restart.
step 3 Click Save to enter the Remote Access interface.
step 4 Enter the login password and click Confirm.
step 5 Access information is saved in the following two ways.
• Click Copy remote access information, and save the access information locally after
successful copying.
• Enter the email address and click Send to send the access information to the email
address.
step 6 Enter the access link in the URL field to enter the Remote Maintenance interface. Enter the
device S/N and password, and click Login to perform remote maintenance.
- - End

7.10.4 Message Export

step 1 Click System→Message Export to enter the corresponding interface.
table 7-4 Parameter description
Parameter
Port
Duration
step 2 Set parameters, including Interface, Serial Port, and Duration, and click Start to start
recording message. The recording automatically stops when the set time reaches, or the
user may manually click the button Stop to stop recoding message.
step 3 Click Export to export the message.
48
Description
-
Export the message
recorded during the set time
Range
Serial port: COM1、COM2、COM3
Network port: ETH, WiFi, 4G
1min ~ 10min
User Manual
