7.7.3.2 Batch setting
step 1 Select the desired Country (region) and Grid type.
step 2 Click Configure Synchronization.
step 3 Select the desired devices in the pop-up device list, and click Save to achieve batch setting.
- - End

7.7.4 Protection Parameter

Click Device monitoring→Protection Parameters to enter the corresponding interface
and set protection parameters.
Protection parameters can be set in two manners: single setting and batch setting. For
specific setting method, refer to

7.7.5 General Parameter

step 1 Click Device monitoring→General Parameters to enter the corresponding interface and
set general parameters.
step 2 Select Read-back, set Register Address, Register Number, and Address Type, and click
the button Read-back, to read the current value of the device.
step 3 Select Settings, set Register Address, Data Type, and set Value, and click the button
Save. Parameters can be set for a single device.
For parameters that need to be set, refer to corresponding communication
protocol of the inverter.
step 4 (Optional) Select Settings, set the Register Address, "Data Type" and set Value, and
Click Configure Synchronization. In the pop-up list of devices, check the devices that
need to be set, and click Save. You can set the parameters for multiple devices.
- - End

7.7.6 Device Instruction

Click Device Monitoring→Device Instruction to enter the corresponding interface.
On this interface, users can boot/shutdown the device or reset all settings.
Device instruction can be set in two manners: single setting and batch setting. Take the boot
operation as an example for explanation.
7.7.6.1 Single setting
step 1 Select a device, click Boot, and a dialog box pops up.
step 2 Click Yes to start a single device.
- - End
"7.7.3 Initial Parameter".
