User Manual
table 7-11 EyeW485 Parameter Description
Parameter
Array ID
Frequency
After finishing the configuration, click Refresh to refresh the current interface.
Operation Instructions
On this interface, users can perform the following operations.
table 7-12 Operation Instruction Description
Function
One-touch Switch
Rebooting (EyeW485–H
only)
Reset All Settings
(EyeW485–H only)
Rebooting (EyeW485–H,
EyeW485)
7.10.10.3 Ethernet
Perform Ethernet settings on this interface.
step 1 Click System→Port Parameter→Ethernet to enter the corresponding interface.
step 2 If auto IP allocation is
port by connecting the WLAN module and logging into 11.11.11.1.
step 3 If the parameter Automatically obtain IP settings (DHCP) is set to
information such as the IP Address, Subnet Mask, and Default Gateway, and click the
button to save the operation.
- - End
The default IP address of the ETH port is 12.12.12.12.
If both auto IP allocation and WLAN STA client are enabled, ensure that the
Ethernet and the WLAN STA are at different network segment. Otherwise, it is
probably that neither of the two networks is available.
Description
Select the array number (red, blue, and green are colors of
the COM indicator of the slave node).
Enter the frequency point in the input box (it must be
consistent with the frequency point of the master node).
Description
Also known as "one-touch frequency hopping". The frequency
points with required signal strength are randomly assigned to
EyeW485 master and slave nodes.
Reboot the master node of EyeW485.
Restore factory settings of the master node of EyeW485.
Reboot the master and slave nodes of EyeW485.
, it is recommended to obtain the current IP address of the ETH
7 WEB Interface
fill in the
