7 WEB Interface
7.7

Device Monitoring

Click Device Monitoring to enter the corresponding interface.
Device information such as real-time values, DC data, initial parameter, protection
parameter, general parameter, device instruction and device information can be viewed on
this interface.

7.7.1 RealTime Values

Realtime information such as power generation, device state, and active power can be
viewed on this interface.
step 1 Click Device Monitoring→Realtime Values to view the corresponding information.
step 2 Click the button
- - End

7.7.2 DC Data

Click Device Monitoring→DC data to view the corresponding information.
On this interface, voltage and current information of multiple inputs of MPPTs and strings
can be viewed.

7.7.3 Initial Parameter

Click Device monitoring→Initial Parameter to enter the corresponding interface and set
initial parameters.
Select the meter, set PT Transformation Ratio, CT Transformation Ratio, Meter Reverse
Connection Enable and Access Type, click Save.
When the meter cable is connected reversed, but it is not easy to change the
wiring, the correct meter data can be obtained after opening the meter reversing
enable switch.
The meter reversal function supports single-phase meters and three-phase
meters. Note that only the reverse connection of three phases is supported, and
the reverse connection of one or two of the three phases is not supported.
Select the inverter, initial parameters can be set in two manners: single setting and batch
setting.
7.7.3.1 Single setting
step 1 Select the desired Country (region) and Grid type.
step 2 Click Settings to set initial parameters for the single device.
- - End
38
to select the device type.
