7 WEB Interface
step 4 Select Others option in the Device Model.
step 5 Select Custom option in the Configuration Method. Click Next to enter Configure
Measuring Point the interface.
table 7-2 Parameter description
Parameter
Byte Order
Beginning Address
Quantity of Device
Debug Address
Read Type
Coefficient
Read-back Value
The user can select up to 13 objects for setting. For the corresponding
parameters(such as register address, register type, etc.), please refer to the user
manual of the connected meteo station.
step 6 Select the points to be measured, click Read-back to read the information from the meteo
station in real-time to check the correctness of parameter setting.
step 7 After confirming that the read-back data is correct, then click Confirm.
step 8 Enter the template name in the pop-up prompt window and click Confirm on the prompt
window to save the template.
The template name should be a combination of numbers, letters, dashes and
underscores starting with English letters, with a maximum length of 32 bits.
step 9 Click Confirm on the measuring point configuring window to add the device and save the
setting.
- - End
7.8.1.9 Edit device
step 1 Click Device→Device List to enter the corresponding interface.
step 2 Click the button
Logger1000 and other parameters.
44
Description
Refer to the device Modbus map, parse the order of the
read byte stream
The beginning address of the device
The number of the device
The device address to be read when click Read-Back,
the range is [("Beginning Address"), ("Beginning
Address" + "Quantity of Device"-1)]
With or without framing when send messages at this
point, recommend to choose continuous type
Refer to the Modbus map of the device, the coefficient
that multiplied the value
The value of the selected measuring point read when
clicking Read-back
in the operation bar, to modify the name of the device connected to the
