7 WEB Interface
7.10.10.2 EyeW485
Click System →Port Parameter→EyeW485 to enter the corresponding interface, on which
users can configure the master and slave nodes of the EyeW485 and send related
operation instructions.
EyeW485–H
On this interface, uses can set the Country/Region, Frequency, and Array of the master
node.
table 7-10 EyeW485-H Parameter Description
Parameter
Country/Region
Frequency
Array
After finishing the configuration, click Settings.
The frequency point of master and slave nodes can be configured simultaneously if the
networking between master and slave nodes is finished. Click Select Measuring Point(s)
to enter the Frequency interface, check the frequency point of the matched country/region,
click Confirm, and click Configure Synchronization.
If there are slave nodes that have not been successfully networked, users will be
prompted with the slave node information (S/N and Device Address) after
clicking Configure Synchronization. Click Export to save the information to
local.
Parameters such as frequency of slave nodes that have not been successfully
networked can be set on near-end devices.
EyeW485
On this interface, users can configure the Frequency points and Arrays of slave nodes,
and can also view the information of slave nodes, such as S/N, Device Address, Status,
and Signal.
Click to set the following parameters：
56
Description
Select the country/region.
Click Select Measuring Point(s) to select the frequency
point of the matched country/region.
Select the array according to the color of the COM indicator
on the slave node.
