9.7.3.2 Batch setting:
step 1 Select the desired country (region) and grid type.
step 2 Click "Configure synchronization".
step 3 Select the desired devices in the pop-up device list, and click "Save" to achieve batch
setting.
- - - - E E n n d d

9.7.4 Protection Parameter

Click "Device monitoring" -> "Protection parameter" to enter the corresponding
interface and set protection parameters.
Protection parameters can be set in two manners: single setting and batch setting. For
specific setting method, refer

9.7.5 General Parameter

step 1 Click "Device monitoring" -> "General parameters" to enter the corresponding interface
and set general parameters.
step 2 Select "Read-back", set register address, register number, and address type, and click
the button "Read-back", to read the current value of the device.
step 3 Select "Setting", set register address, data type, and set value, and click the button "-
Save", to set device parameters.
- - - - E E n n d d

9.7.6 Device Instruction

Click "Device monitoring" -> "Device instruction" to enter the corresponding interface.
On this interface, users can boot/shutdown the device or reset all settings.
Device instruction can be set in two manners: single setting and batch setting. Take the
boot operation as an example for explanation.
9.7.6.1 Single setting
step 1 Select a device, click "boot", and a dialog box pops up.
step 2 Click "Yes" to start a single device.
- - - - E E n n d d
9.7.6.2 Batch setting
step 1 Select a device, click "boot", and a dialog box pops up.
step 2 Click "Configure synchronization".
to"9.7.3 Initial Parameter".
