INVT Goodrive20-EU Series Operation Manual page 153

Goodrive20-EU Series VFD
Model
GD20-0R4G-S2-EU
GD20-0R7G-S2-EU
GD20-1R5G-S2-EU
GD20-2R2G-S2-EU
GD20-0R4G-2-EU
GD20-0R7G-2-EU
GD20-0R7G-4-EU
GD20-1R5G-4-EU
GD20-2R2G-4-EU
Figure B-5 Rail mounting of VFDs of 1PH 220V/3PH 380V (≤2.2kW) and 3PH 220V (≤0.75kW)
Model
GD20-0R4G-S2-EU
GD20-0R7G-S2-EU
GD20-1R5G-S2-EU
GD20-2R2G-S2-EU
GD20-0R4G-2-EU
GD20-0R7G-2-EU
GD20-0R7G-4-EU
GD20-1R5G-4-EU
GD20-2R2G-4-EU
W1 W2 H1
80.0 60.0 160.0
80.0 60.0 160.0
80.0 60.0 185.0
80.0 60.0 185.0
80.0 60.0 185.0
80.0 60.0 185.0
80.0 60.0 185.0
80.0 60.0 185.0
80.0 60.0 185.0
(Dimension unit: mm)
W1 H1
80.0 160.0
80.0 160.0
80.0 185.0
80.0 185.0
80.0 185.0
80.0 185.0
80.0 185.0
80.0 185.0
80.0 185.0
H2 D1
150.0 123.5 120.3
150.0 123.5 120.3
175.0 140.5 137.3
175.0 140.5 137.3
175.0 140.5 137.3
175.0 140.5 137.3
175.0 140.5 137.3
175.0 140.5 137.3
175.0 140.5 137.3
H3 H4 D1
35.4 36.6 123.5 120.3
35.4 36.6 123.5 120.3
35.4 36.6 140.5 137.3
35.4 36.6 140.5 137.3
35.4 36.6 140.5 137.3
35.4 36.6 140.5 137.3
35.4 36.6 140.5 137.3
35.4 36.6 140.5 137.3
35.4 36.6 140.5 137.3
-148-
Dimension drawings
Mounting
D2 hole
diameter (d)
Ø 5
Ø 5
Ø 5
Ø 5
Ø 5
Ø 5
Ø 5
Ø 5
Ø 5
Mounting
hole
D2
diameter
(d)
Ø 5
Ø 5
Ø 5
Ø 5
Ø 5
Ø 5
Ø 5
Ø 5
Ø 5
Weight
(kg)
0.9
0.9
1.2
1.2
1
1
1
1
1
Weight
(kg)
0.9
0.9
1.2
1.2
1
1
1
1
1
