Goodrive20-EU Series VFD

P17 group Status viewing

Function
Name
code
Setting
P17.00
frequency
Output
P17.01
frequency
Ramp
P17.02 reference
frequency
P17.03 Output voltage
P17.04 Output current
P17.05 Motor speed
P17.06 Torque current
Magnetized
P17.07
current
P17.08 Motor power
P17.09 Output torque
Motor
P17.10 frequency
evaluation
P17.11 DC bus voltage
Switch input
P17.12
terminals state
Switch output
P17.13
terminals state
Digital
P17.14
adjustment
Display current set frequency of the VFD
Range: 0.00Hz–P00.03
Display current output frequency of the VFD
Range: 0.00Hz–P00.03
Display current ramp reference frequency of the
VFD
Range: 0.00Hz–P00.03
Display current output voltage of the VFD
Range: 0–1200V
Display current output current of the VFD
Range: 0.0–5000.0A
Display the rotation speed of the motor.
Range: 0–65535RPM
Display current torque current of the VFD
Range: 0.0–5000.0A
Display current magnetized current of the VFD
Range: 0.0–5000.0A
Display current power of the motor.
Setting range: -300.0%–300.0%
(the rated current of the motor)
Display the current output torque of the VFD.
Range: -250.0–250.0%
Evaluate the motor rotor frequency on open loop
vector
Range: 0.00–P00.03
Display current DC bus voltage of the VFD
Range: 0.0–2000.0V
Display current Switch input terminals state of
the VFD
Range: 0000–00FF
Display current Switch output terminals state of
the VFD
Range: 0000–000F
Display the adjustment through the keypad of the
VFD.
Range : 0.00Hz–P00.03
Description
-98-
Function parameters
Default Modify
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
