Goodrive20-EU Series VFD
Function
Name
code
Torque current
P17.34
reference
AC input
P17.35
current
P17.36 Output torque
Motor overload
P17.37
counting
P17.38 PID output
Parameter
P17.39
download error
Process PID
P17.40 proportional
gain
Process PID
P17.41
integral time
Process PID
P17.42
differential time
Display the torque current reference in the vector
control mode.
Range: -3000.0–3000.0A
Display the input current in AC side.
Range: 0.0–5000.0A
Display the output torque. Positive value is in the
electromotion state, and negative value is in the
power generating state.
Range: -3000.0Nm–3000.0Nm
0–100 (Display the "OL1" fault when the count
value is 100)
Display PID output
-100.00–100.00%
0.00–99.99
0.00–100.00
0.00–10.00s
0.00–10.00s
Description
-100-
Function parameters
Default Modify
●
●
●
●
●
●
0.00
●
●
●
