Goodrive20-EU Series VFD
sum of the lengths of the motor cables) into account. When the total length is longer than 50 m,
an output reactor must be added on the output side of the VFD. If the distance between the
VFD and motor is 50 m to 100 m, select the reactor according to the following table. If the
distance is longer than 100 m, contact INVT's technical support technicians.
Model
GD20-0R4G-S2-EU
GD20-0R7G-S2-EU
GD20-1R5G-S2-EU
GD20-2R2G-S2-EU
GD20-0R4G-2-EU
GD20-0R7G-2-EU
GD20-1R5G-2-EU
GD20-2R2G-2-EU
GD20-004G-2-EU
GD20-5R5G-2-EU
GD20-7R5G-2-EU
GD20-0R7G-4-EU
GD20-1R5G-4-EU
GD20-2R2G-4-EU
GD20-004G-4-EU
GD20-5R5G-4-EU
GD20-7R5G-4-EU
GD20-011G-4-EU
GD20-015G-4-EU
GD20-018G-4-EU
GD20-022G-4-EU
GD20-030G-4-EU
GD20-037G-4-EU
GD20-045G-4-EU
Input reactor
Output reactor
Input reactor
ACL2-1R5-4
ACL2-1R5-4
ACL2-004-4
ACL2-004-4
ACL2-5R5-4
ACL2-7R5-4
ACL2-015-4
ACL2-1R5-4
ACL2-1R5-4
ACL2-2R2-4
ACL2-004-4
ACL2-5R5-4
ACL2-7R5-4
ACL2-011-4
ACL2-015-4
ACL2-018-4
ACL2-022-4
ACL2-037-4
ACL2-037-4
ACL2-045-4
-157-
Optional peripheral accessories
Output reactor
OCL2-1R5-4
OCL2-1R5-4
OCL2-004-4
OCL2-004-4
OCL2-5R5-4
OCL2-7R5-4
OCL2-015-4
OCL2-1R5-4
OCL2-1R5-4
OCL2-2R2-4
OCL2-004-4
OCL2-5R5-4
OCL2-7R5-4
OCL2-011-4
OCL2-015-4
OCL2-018-4
OCL2-022-4
OCL2-037-4
OCL2-037-4
OCL2-045-4
