INVT Goodrive20-EU Series Operation Manual page 94

Goodrive20-EU Series VFD
Function
Name
code
Multi-step
P10.14
speed 6
Running time
P10.15
of step 6
Multi-step
P10.16
speed 7
Running time
P10.17
of step 7
Multi-step
P10.18
speed 8
Running time
P10.19
of step 8
Multi-step
P10.20
speed 9
Running time
P10.21
of step 9
Multi-step
P10.22
speed 10
Running time
P10.23
of step 10
Multi-step
P10.24
speed 11
Running time
P10.25
of step 11
Multi-step
P10.26
speed 12
Running time
P10.27
of step 12
Multi-step
P10.28
speed 13
Running time
P10.29
of step 13
Multi-step
P10.30
speed 14
Running time
P10.31
of step 14
Multi-step
P10.32
speed 15
Output frequency
Terminal 1
(16)
Terminal 2
(17)
Terminal 3
(18)
Terminal 4
(19)
When terminal1= terminal 2= terminal 3=
terminal 4=OFF, the frequency input manner is
selected via code P00.06 or P00.07. When all
terminals aren't off, it runs at multi-step which
takes precedence of keypad, analog value,
high-speed pulse,
frequency input. Select at most 16 steps speed
via the combination code of terminal 1, terminal
2, terminal 3, and terminal 4.
The start-up and stopping of multi-step running is
determined by function code P00.06, the
relationship between
terminal 1 (16) terminal 2 (17),terminal 3 (18),
terminal 4 (19) and multi-step speed is as
following:
Terminal 1 OFF ON
Terminal 2 OFF OFF
Terminal 3 OFF OFF OFF OFF ON ON ON ON
Terminal 4 OFF OFF OFF OFF OFF OFF OFF OFF
step 0 1
Terminal 1 OFF ON
Terminal 2 OFF OFF
Terminal 3 OFF OFF OFF OFF ON ON ON ON
Terminal 4 ON ON
Setting range
-100.0–100.0%
Description
PLC, communication
OFF ON OFF ON OFF ON
ON ON OFF OFF ON ON
2 3 4
OFF ON OFF ON OFF ON
ON ON OFF OFF ON ON
ON ON ON ON ON ON
of P10.(2n,
-89-
Function parameters
Default Modify
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
0.0s
0.0%
5 6 7
0.0s
0.0%
0.0s
1<n<17):
0.0%
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
