Fault
Fault type
code
[16] Inverter
OH2 module
overheat
[17] External
EF
fault
[18] 485
CE communication
fault
[19] Current
ItE
detection fault
[20] Motor
tE
autotuning fault
[21] EEPROM
EEP
operation fault
Possible cause

SI external fault input
terminals acts.

The baud rate setting is
incorrect;

Fault occurs to the
communication circuit;

The communication
address is wrong;

There is strong
interference to the
communication.

The connection of the
control board is not good;

Assistant power is bad;

Hall components is
broken;

The magnifying circuit is
abnormal.

The motor capacity does
not match with VFD
capacity;

The rated parameter of the
motor is set improperly;

The deviation between the
parameters from autotune
and the standard
parameter is huge;

Autotune overtime.

Error occurred to R/W of
the control parameter;

EEPROM is damaged.
-109-
Solutions
temperature;

Check and reconnect;

Change the power;

Change the power unit;

Change the main control
panel.

Check the external device
input.

Set proper baud rate;

Check the wiring of
communication connection
interface;

Set proper communication
address;

Chang or replace the
wiring or improve the
anti-interference capability.

Check the connector and
plug wire again;

Change the hall;

Change the main control
panel.

Change the VFD model;
Set the rated parameter
according to the motor
nameplate;

Empty the motor load;
Check the motor
connection and set the
parameter;

Check if the upper limit
frequency is above 2/3 of
the rated frequency.

Press STOP/RST to reset;

Change the main control
panel.
