INVT Goodrive20-EU Series Operation Manual page 95

Goodrive20-EU Series VFD
Function
Name
code
Running time
P10.33
of step 15
Acceleration/
deceleration
P10.34 time selection
of simple PLC
0–7 step
Acceleration/
deceleration
P10.35 time selection
of simple PLC
8–15 step
PLC restart
P10.36
mode
Multi-step time
P10.37
unit selection
Setting range
0.0–6553.5s (min)
Below is the detailed instruction:
Function
Binary bit
code
BIT1 BIT0
BIT3 BIT2
BIT5 BIT4
BIT7 BIT6
P10.34
BIT9 BIT8
BIT11 BIT10
BIT13 BIT12
BIT15 BIT14
BIT1 BIT0
BIT3 BIT2
BIT5 BIT4
BIT7 BIT6
P10.35
BIT9 BIT8
BIT11 BIT10
BIT13 BIT12
BIT15 BIT14
After the users
ACC/DEC time, the combining 16 binary bit will
change into decimal bit, and then set the
corresponding function codes.
Setting range: -0x0000–0xFFFF
0: Restart from the first stage; stop during
running (caused by the stop command, fault or
power loss), run from the first stage after restart.
1: Continue to run from the stop frequency; stop
during running (cause by stop command and
fault), the VFD will record the running time
automatically, enter into the stage after restart
and keep the remaining running at the setting
frequency.
0: Seconds; the running time of all stages is
counted by second
Description
of P10.(2n+1,
ACC/ ACC/
Step
DEC 0 DEC 1
0 00 01
1 00 01
2 00 01
3 00 01
4 00 01
5 00 01
6 00 01
7 00 01
8 00 01
9 00 01
10 00 01
11 00 01
12 00 01
13 00 01
14 00 01
15 00 01
select the corresponding
-90-
Function parameters
Default Modify
1<n<17):
0.0s
ACC/ ACC/
0x0000
DEC 2 DEC 3
10 11
10 11
10 11
10 11
10 11
10 11
10 11
10 11
10 11
10 11
10 11
0x0000
10 11
10 11
10 11
10 11
10 11
0
0
○
○
○
◎
◎
