Goodrive20-EU Series VFD
Function
VFD fault code
Identifying code of
the VFD
Operation frequency
Setting frequency
Bus voltage
Output voltage
Output current
Operation speed
Output power
Output torque
PID setting
PID feedback
Input state
Input state
AI 1
AI 2
AI 3
AI 4
Read high speed
pulse 1 input
Read high speed
pulse 2 input
Address
=10: communication control
2102H See the fault type instruction
2103H GD20-EU-----0x0180
0–Fmax,
3000H
0.01Hz
0–Fmax,
3001H
0.01Hz
0.0–2000.0V, unit:
3002H
0.1V
3003H 0–1200V, unit: 1V
0.0–3000.0A, unit:
3004H
0.1A
0–65535,
3005H
1RPM
-300.0–300.0%,
3006H unit:
0.1%
-250.0–250.0%,
3007H
unit: 0.1%
-100.0–100.0%,
3008H
unit: 0.1%
-100.0–100.0%,
3009H
unit: 0.1%
300AH 000–1FF
300BH 000–1FF
0.00–10.00V, unit:
300CH
0.01V
0.00–10.00V, unit:
300DH
0.01V
-10.00–10.00V,
300EH
unit: 0.01V
300FH Reserved
0.00–50.00kHz,
3010H
unit: 0.01Hz
3011H Reserved
Data description
unit:
unit:
unit:
Compatible with
the
communication
addresses of
GD, CHF100A,
and CHV100
series.
-133-
Communication protocol
R/W
characteristics
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
