Goodrive20-EU Series VFD
Function
Name
code
S5 terminal
P05.05 function
selection
S6 terminal
P05.06 function
selection
S7 terminal
P05.07 function
selection
S8 terminal
P05.08 function
selection
HDI terminal
P05.09 function
selection
10: Increasing frequency setting (UP)
11: Decreasing frequency setting (DOWN)
12: Cancel the frequency change setting
13: Shift between A setting and B setting
14: Shift between combination setting and A
setting
15: Shift between combination setting and B
setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
20: Multi-step speed pause
21: ACC/DEC time selection terminal 1
22: ACC/DEC time selection terminal 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Wobbling frequency pause (stop at present
frequency)
27: Wobbling frequency reset (return to center
frequency)
28: Counter reset
29: Torque control prohibition
30: ACC/DEC prohibition
31: Counter trigger
32: Reserved
33: Cancel the frequency change setting
temporarily
34: DC brake
35: Reserved
36: Shift the command to keypad
37: Shift the command to terminals
38: Shift the command to communication
39: Pre-magnetized command
40: Clear the power consumption
41: Keep the power consumption
42: Emergency stop
43–60: Reserved
Description
-58-
Function parameters
Default Modify
◎
0
◎
0
◎
0
◎
0
◎
0
