INVT Goodrive20-EU Series Operation Manual page 56

Goodrive20-EU Series VFD
Function
Name
code
rotation in
torque control
Setting source
of upper-limit
frequency of
P03.15
reverse
rotation in
torque control
Torque control
forward
rotation
P03.16 upper-limit
frequency
keypad limit
value
Torque control
reverse
rotation
P03.17 upper-limit
frequency
keypad limit
value
Upper-limit
setting of
P03.18
electromotion
torque
Upper-limit
P03.19 setting of
braking torque
2: Set via AI2 (same as above)
3: Set via AI3 (same as above)
4: Set via pulse frequency HDI (same as above)
5: Set via multi-step (same as above)
6: Set via Modbus communication (same as
above)
7–9: Reserved
Note: setting method 1–9, 100% corresponds to
the maximum frequency
This function is used to set the upper limit of the
frequency. P03.16 sets the value of P03.14;
P03.17 sets the value of P03.15.
Setting range: 0.00 Hz–P00.03 (the max. output
frequency)
This function code is used to select the
electromotion and braking torque upper-limit
setting source selection.
0: Set via keypad (P03.20 sets P03.18 and
P03.21 sets P03.19)
1: Set via AI1 (100% relative to three times of
motor current)
2: Set via AI2 (same as above)
3: Set via AI3 (same as above)
4: Set via HDI (same as above)
5: Set via Modbus communication (same as
above)
6–8: Reserved
Note: Setting mode 1–8, 100% corresponds to
three times of the motor current.
Description
-51-
Function parameters
Default Modify
○
0
50.00
○
Hz
50.00
○
Hz
○
0
○
0
