4.1 Keypad introduction

You can use the keypad to control the start and stop, read status data, and set parameters of
the VFD.
Note:
 A film-type keypad is a standard configuration for the VFD models of 1PH 230V/3PH 400V
(≤2.2kW) and 3PH (≤0.75kW). An external keypad is a standard configuration for the VFD
models of 3PH 400V (≥4kW) and 3PH 230V (≥1.5kW).
 In addition, if you need, an external keypad (an optional part) can be provided (including the
external keypads with and without the function of parameter copying).

Chapter 4 Keypad operation

RUN/TUNE
PRG
ESC
QUICK
JOG
RUN
Figure 4-1 Film-type keypad
RUN/TUNE FWD/REV
3
PRG
ESC
QUICK
JOG
RUN
Figure 4-2 External keypad
FWD/REV LOCAL/REMOT TRIP 1
HZ
2
RPM
A
%
V
DATA
SHIFT
STOP
RST
LOCAL/REMOT TRIP
1
HZ
RPM
A
%
V
2
5
DATA
SHIFT
STOP
4
RST
