INVT Goodrive20-EU Series Operation Manual page 39

Goodrive20-EU Series VFD
Function
Name
code
Run command
P00.01
channel
Max. output
P00.03
frequency
Upper limit of
P00.04 running
frequency
and torque. It does not need to install pulse
encoder.
2: SVPWM control
Suitable in applications which do not need high
control accuracy, such as the load of fan and
pump. One VFD can drive multiple motors.
Note: Motor parameter autotuning is required
when vector mode is applied.
Select the run command channel of the VFD.
The control command of the VFD includes: start,
stop, forward/reverse rotating, jogging and fault
reset.
0: Keypad ("LOCAL/REMOT" light off)
Carry out the command control by RUN,
STOP/RST on the keypad.
Set the multi-function key QUICK/JOG to
FWD/REVC shifting function (P07.02=3) to
change the running direction; press RUN and
STOP/RST simultaneously in running state to
make the VFD coast to stop.
1: Terminal ("LOCAL/REMOT" flickering)
Carry out the running command control by the
forward rotation, reverse rotation and forward
jogging and reverse jogging of the multi-function
terminals
2:Communication ("LOCAL/REMOT" on);
The running command is controlled by the upper
monitor via communication
The parameter is used to set the max. output
frequency of the VFD. It is the basis of frequency
setup and the acceleration/deceleration.
Setting range: P00.04–400.00Hz
The upper limit of the running frequency is the
upper limit of the output frequency of the VFD
which is lower than or equal to the maximum
frequency.
Setting range: P00.05–P00.03 (max. output
frequency)
Description
-34-
Function parameters
Default Modify
○
0
◎
50.00Hz
◎
50.00Hz
