INVT Goodrive20-EU Series Operation Manual page 60

Goodrive20-EU Series VFD
Function
Name
code
V/F voltage
P04.06
point 2
V/F frequency
P04.07
point 3
V/F voltage
P04.08
point 3
V/F slip
P04.09 compensation
gain
Low frequency
P04.10 vibration
control factor
High frequency
P04.11 vibration
control factor
Vibration
P04.12 control
threshold
When P04.00 =1, the user can set V//F curve
through P04.03–P04.08.
V/F is generally set according to the load of the
motor.
Note: V1<V2<V3, f1<f2<f3. Too high low
frequency voltage will heat the motor excessively
or damage. Overcurrent stall or overcurrent
protection may occur.
Setting range of P04.03: 0.00Hz–P04.05
Setting range of P04.04, P04.06 and P04.08:
0.0%–110.0% (rated motor voltage)
Setting range of P04.05: P04.03–P04.07
Setting range of P04.07: P04.05–P02.02 (rated
motor voltage frequency)
This function code is used to compensate the
change of the rotation speed caused by load
during compensation SVPWM control to improve
the rigidity of the motor. It can be set to the rated
slip frequency of the motor which is counted as
below:
△f=f
-n*p/60
b
Of which, f is the rated frequency of the motor,
b
its function code is P02.02; n is the rated rotating
speed of the motor and its function code is
P02.03; p is the pole pair of the motor. 100.0%
corresponds to the rated slip frequency△f.
Setting range: 0.0–200.0%
In the SVPWM control mode, current fluctuation
may occur to the motor on some frequency,
especially the motor with big power. The motor
cannot run stably or overcurrent may occur.
These phenomena can be canceled by adjusting
this parameter.
Setting range of P04.10: 0–100
Setting range of P04.11: 0–100
Setting range of P04.12: 0.00Hz–P00.03 (the
max. frequency)
Description
-55-
Function parameters
Default Modify
○
0.0%
○
0.00Hz
○
0.0%
○
100.0%
○
10
○
10
30.00
○
Hz
