Goodrive20-EU Series VFD
Function
Name
code

P13 group SM control

Function
Name
code
Frequency
P13.09 switching
point
Short circuit
P13.13
brake current
Hold time of
P13.14 short circuit
brake at start
Hold time of
P13.15 short circuit
brake at stop

P14 group Serial communication

Function
Name
code
local
P14.00 communication
address
1: STO alarm unlocked
STO alarm unlocked means when STO appears,
STO alarm will disappeared automatically after
state recovery.
Note: STL1–STL3 are fault lock and cannot be
reset.
0.00–630.00
After the VFD starts, when P01.00=0, set P13.14
to non-zero value and begin short circuit braking.
After the VFD stops, when the operation
frequency is less than P01.09, set P13.15 to
non-zero value and begin stopping short-circuit
braking and then DC braking.
Setting range of P13.13: 0.0–150.0% (relative to
the percentage of rated current of the VFDs)
Setting range of P13.14: 0.00–50.00s
Setting range: 1–247
When the master is writing the frame, the
communication address of the slave is set to 0;
the broadcast address is the communication
address. All slaves on the Modbus fieldbus can
receive the frame, but the salve doesn't answer.
The communication address of the drive is
unique in the communication net. This is the
fundamental for the point to point communication
between the upper monitor and the drive.
Note: The address of the slave cannot set to 0.
Description
Description
Description
-95-
Function parameters
Default Modify
Default Modify
○
50.00
○
0.0%
○
0.00s
○
0.00s
Default Modify
○
1
