code
P07.44 Output current of the last fault
P07.45 Bus voltage of the last fault
P07.46 Max. temperature of the last fault
P07.47 Input terminals state of the last fault
P07.48 Output terminals state of the last fault
P07.49 Reference frequency of the last but one fault
P07.50 Ramp reference frequency of last but one fault
P07.51 Output voltage of the last but one fault
P07.52 Output current of the last but one fault
P07.53 Bus voltage of the last but one fault
P07.54 Max. temperature of the last but one fault
P07.55 Input terminals state of the last but one fault
P07.56 Output terminals state of the last but one fault

P08 group Enhanced functions

Function
Name
code
P08.00 ACC time 2
P08.01 DEC time 2
P08.02 ACC time 3
P08.03 DEC time 3
P08.04 ACC time 4
P08.05 DEC time 4
When the terminal acts as ACC/DEC time
selection (see terminal function settings in the
P05 group), you need to select four groups of
ACC/DEC time through state combinations of
these two terminals.
Terminal Terminal
1 (21) 2 (22)
OFF OFF
ON OFF
OFF ON
ON ON
Refer to P00.11 and P00.12 for detailed
definition.
The first group of ACC/DEC time is the factory
default one.
Setting range: 0.0–3600.0s
Description
Description
ACC/DEC time
setting
ACC/DEC time 1
ACC/DEC time 2
ACC/DEC time 3
ACC/DEC time 4
-74-
Function parameters
Default Modify
0.0A
0.0V
0.0° C
0
0
0.00Hz
0.00Hz
0V
0.0A
0.0V
0.0° C
0
0
Default Modify
Parameters
P00.11/
P00.12
Depend
P08.00/
on
P08.01
model
P08.02/
P08.03
P08.04/
P08.05
●
●
●
●
●
●
●
●
●
●
●
●
●
○
○
○
○
○
