Goodrive20-EU Series VFD
Function
Name
code
Torque
P17.15
reference
P17.16 Linear speed
P17.18 Counting value
AI1 input
P17.19
voltage
AI2 input
P17.20
voltage
AI3 input
P17.21
voltage
HDI input
P17.22
frequency
PID reference
P17.23
value
PID feedback
P17.24
value
Power factor of
P17.25
the motor
Current
P17.26
running time
Simple PLC
and present
P17.27 stage of
multi-step
speed
ASR controller
P17.28
output
Magnetic flux
P17.32
linkage
Exciting current
P17.33
reference
Display the torque reference, the percentage to
the current rated torque of the motor.
Setting range: -300.0%–300.0%
(of the rated motor current)
Display the current linear speed of the VFD.
Range: 0–65535
Display current counting number of the VFD.
Range: 0–65535
Display analog AI1 input signal
Range: 0.00–10.00V
Display analog AI2 input signal
Range: 0.00–10.00V
Display analog AI2 input signal
Range: -10.00–10.00V
Display HDI input frequency
Range: 0.000–50.000kHz
Display PID reference value
Range: -100.0–100.0%
Display PID feedback value
Range: -100.0–100.0%
Display the current power factor of the motor.
Range: -1.00–1.00
Display the current running time of the VFD.
Range: 0–65535min
Display simple PLC and the current stage of the
multi-step speed
Range: 0–15
The percentage of the rated torque of the relative
motor, display ASR controller output
Range: -300.0%–300.0% (rated motor current)
Display the magnetic flux linkage of the motor.
Range: 0.0%–200.0%
Display the exciting current reference in the
vector control mode.
Range: -3000.0–3000.0A
Description
-99-
Function parameters
Default Modify
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
