Goodrive20-EU Series VFD

P06 group Output terminals

Function
Name
code
Y1 output
P06.01
selection
Relay RO1
P06.03 output
selection
Relay RO2
P06.04 output
selection
Polarity
selection of
P06.05
output
terminals
0: Invalid
1: In operation
2: Forward rotation operation
3: Reverse rotation operation
4: Jogging operation
5: The VFD fault
6: Frequency level test FDT1
7: Frequency level test FDT2
8: Frequency reached
9: In zero-speed operation (output in running
state)
10: Upper limit frequency reached
11: Lower limit frequency reached
12: Ready for operation
13: Pre-magnetizing
14: Overload pre-alarm
15: Underload pre-alarm
16: Completion of simple PLC stage
17: Completion of simple PLC cycle
18: Setting count value arrival
19: Defined count value arrival
20: External fault valid
21: Zero-speed output (output in both running
and stopping states)
22: Running time arrival
23: Modbus communication virtual terminals
output
24–25: Reserved
26: Establishment of DC bus voltage
27: STO action
28–30: Reserved
The function code is used to set the pole of the
output terminal.
When the current bit is set to 0, input terminal is
positive.
When the current bit is set to 1, input terminal is
negative.
Description
-65-
Function parameters
Default Modify
○
0
○
1
○
5
○
0
