Goodrive20-EU Series VFD
ASCII mode:
The command sent to the VFD:
If the operation succeeds, the response message is as follows:
The data content is 0003H. According to the parameter table of other functions, the VFD stops.

7.5.2 Examples of write command 06H

Example 1: Make the VFD with the address of 03H to run forward. See section 7.4.2
"Description of other function addresses in Modbus", the address of "Communication-based
control command" is 2000H, and 0001H indicates forward running. See the table below.
Function
Communication-based
control command
RTU mode:
The command sent by the master:
VFD
address
VFD
Read
address
command
VFD
Read
command
address
Address
2000H
Write
command
Parameters
Data
address
number
Data
Byte
content
number
Data description
0001H: Forward running
0002H: Reverse running
0003H: Forward jogging
0004H: Reverse jogging
0005H: Stop
0006H: Coast to stop (emergency
stop)
0007H: Fault reset
0008H: Jogging stop
Parameters
Forward
address
running
-138-
Communication protocol
LRC
check
LRC
check
characteristics
CRC check
R/W
R/W
