INVT Goodrive20-EU Series Operation Manual page 52

Goodrive20-EU Series VFD
Function
Name
code
Stator resistor
P02.06
of async-motor
Rotor resistor
P02.07
of async-motor
Leakage
P02.08 inductance of
async-motor
Mutual
P02.09 inductance of
async-motor
Non-load
P02.10 current of
async-motor
Magnetic
saturation
P02.11 coefficient 1 for
iron core of
async-motor 1
Magnetic
saturation
P02.12 coefficient 2 for
iron core of
async-motor 1
Magnetic
saturation
P02.13 coefficient 3 for
iron core of
async-motor 1
Magnetic
saturation
P02.14 coefficient 4 for
the iron core of
async-motor 1
0.001–65.535Ω
0.001–65.535Ω
0.1–6553.5mH
0.1–6553.5mH
0.1–6553.5A
0.0–100.0%
0.0–100.0%
0.0–100.0%
0.0–100.0%
Description
-47-
Function parameters
Default Modify
model
Depend
○
on
model
Depend
○
on
model
Depend
○
on
model
Depend
○
on
model
Depend
○
on
model
◎
80.0%
◎
68.0%
◎
57.0%
◎
40.0%
