Goodrive20-EU Series VFD
Environment
Storage
-40° C to +70° C, and the temperature changing rate is less than 1° C/minute.
temperature
The installation site of the VFD should fulfill the following requirements.
 Away from electromagnetic radiation sources.
 Away from oil mist, corrosive gases and combustible gases.
 Ensure foreign object like metal powder, dust, oil and water will not fall into
Running
environment
 Away from radioactive substance and combustible objects.
condition
 Away from harmful gases and liquids.
 Low salt content.
 No direct sunlight.
 Below 1000m.
 When the altitude exceeds 3000m, consult the local INVT dealer or office
Altitude
 When the altitude exceeds 1000m, derate by 1% for every increase of
Vibration Max. vibration acceleration: 5.8m/s
Installation The VFD should be installed on an upright position to ensure sufficient cooling
direction effect.
Note:
 Goodrive20-EU series VFDs should be installed in a clean and ventilated environment
according to enclosure classification.
 Cooling air must be clean, free from corrosive materials and electrically conductive dust.

3.1.2 Installation direction

The VFD may be installed in a cabinet.
The VFD needs be installed in the vertical position. Check the installation site according to the
requirements below. Refer to Appendix B "Dimension drawings" for details.

3.1.3 Installation mode

a) Wall and rail mounting for the VFDs (single phase 230V/three phase 400V, ≤2.2KW and
three phase 230V, ≤0.75KW)
the VFD (do not install the VFD onto combustible object like wood).
for details.
100m.
Conditions
2
(0.6g)
-15-
Installation guidelines
