INVT Goodrive20-EU Series Operation Manual page 69

Goodrive20-EU Series VFD
Function
Name
code
Middle value of
P05.44
AI3
Corresponding
P05.45 middle setting
of AI3
Upper limit of
P05.46
AI3
Corresponding
setting of
P05.47
the upper limit
of AI3
AI3 input filter
P05.48
time
Lower limit
P05.50 frequency of
HDI
Corresponding
setting of HDI
P05.51
low frequency
setting
Upper limit
P05.52 frequency of
HDI
Corresponding
setting of upper
P05.53
limit frequency
of HDI
HDI frequency
P05.54
input filter time
Setting range of P05.32: 0.00V–P05.34
Setting range of P05.33: -100.0%–100.0%
Setting range of P05.34: P05.32–10.00V
Setting range of P05.35: -100.0%–100.0%
Setting range of P05.36: 0.000s–10.000s
Setting range of P05.37: 0.00V–P05.39
Setting range of P05.38: -100.0%–100.0%
Setting range of P05.39: P05.37–10.00V
Setting range of P05.40: -100.0%–100.0%
Setting range of P05.41: 0.000s–10.000s
Setting range of P05.42: -10.00V–P05.44
Setting range of P05.43: -100.0%–100.0%
Setting range of P05.44: P05.42–P05.46
Setting range of P05.45: -100.0%–100.0%
Setting range of P05.46: P05.44–10.00V
Setting range of P05.48: 0.000s–10.000s
0.000kHz–P05.52
-100.0%–100.0%
P05.50–50.000kHz
-100.0%–100.0%
0.000s–10.000s
Description
-64-
Function parameters
Default Modify
○
0.00V
○
0.0%
○
10.00V
○
100.0%
○
0.100s
0.000
○
kHz
○
0.0%
50.000
○
kHz
○
100.0%
○
0.100s
