Goodrive20-EU Series VFD

2.8 Structure diagram

The following figure shows the structure of the VFD (3PH 400V, ≤2.2kW) (using the 0.75kW
VFD model as the example).
No.
1 External keypad port
2 Port cover
3
4 Hole for the sliding cover Fix the sliding cover
5 Trunking board
6 Name plate
7 Potentiometer knob
8 Control terminals
9 Main circuit terminals
10 Screw hole
11 Cooling fan
12 Fan cover
13 Bar code
Note: In above figure, the screws at 4 and 10 are provided with packaging and specific
installation depends on the requirements of customers.
1
2
3
4
1 3
5
Figure 2-3 Product structure (3PH 400V, ≤2.2kW)
Name
Connect the external keypad
Protect the external keypad port
Cover Protect the internal parts and components
Protect the inner components and fix the cables of the
main circuit
See section 2.5 "Product nameplate" for details.
Refer to Chapter 4 "Keypad operation".
See Chapter 3 "Installation guidelines" for details.
See Chapter 3 "Installation guidelines" for details.
Fix the fan cover and fan.
See Chapter 6 "Fault tracking" for details.
Protect the fan
The same as the bar code on the name plate
Note: The bar code is on the middle shell which is under
the cover.
Description
-12-
Product overview
6
7
8
9
10
11
12
