Goodrive20-EU Series VFD
Function
Name
code
Action selected
when running
frequency less
than frequency
P01.19 lower limit
(valid when
frequency
lower limit is
larger than 0)
Wake–up–from
P01.20
-sleep delay
Restart after
P01.21
power off
The waiting
P01.22 time of restart
after power off
0x00–0x12
Ones place:
0: Run at the frequency lower limit
1: Stop
2: Sleep
Tens place: Stop mode
0: Coast to stop
1: Decelerate to stop
This function
wake-up-from-sleep
running frequency of the VFD is lower than the
lower limit, the VFD becomes standby.
When the set frequency exceeds the lower limit
one again and it lasts for the time set by P01.20,
the VFD runs automatically.
Frequency f
t1 < P01.20, the VFD does not run
t1+t2 ≥P01.20, the VFD runs
Frequency
lower limit f0
Coast to
Run
stop
Setting range: 0.0–3600.0s (valid when
P01.19=2)
This function can enable the VFD to start or not
after power off and power on.
0: Disabled
1: Enabled, if the starting need is met, the VFD
will run automatically after waiting for the time
defined by P01.22.
The function determines the waiting time before
the automatic running of the VFD when powering
off and powering on.
Description
code determines
delay time. When
Set frequency curve:
Running frequency curve:
t2
t1
Sleep Run
-45-
Function parameters
Default Modify
0x00
the
the
0.0s
Time t
0
1.0s
◎
○
○
○
