5-30 C 5: M
HAPTER
reflect the types of networking hardware available. The range of
choices will change as the range of protocols supported increases.
File Name
you want to download several files, you should enter each file name
separated by a colon.
Server Address
contains the files.
Download State
the download procedure.
IP address format and IPX address format are read-only reminder data.
If you lose your software image totally, contact 3Com Technical
Support.
The management module also enables you to download updates to
the software used by MSH Smart Modules. All Smart Repeater Modules
use the same software. New versions of the Smart Module software are
loaded to flash EPROM into an unused area of memory. At some time
in the future, you may find that an attempted download is greeted with
a 'Fail' message. In this case, you will need to download a complete
software image — for both management and Smart Modules. The
downloading of the software for the management module is a separate
operation from downloading the Smart Module software.
CAUTION: Following an upgrade of the management software, the
Smart Modules will adopt the configuration set by the hardware links.
When setting up the hardware links on all modules, you must ensure
that you provide a path between the TFTP server and Ethernet
backplane bus 1 so that you can download management and Smart
Module software. The most common causes of failure to download the
software are the port connected to the TFTP server is hard-linked as
disable-on-boot and the module carrying that port is hard-linked to an
Ethernet bus other than bus 1.
T C
ANAGING HE HASSIS
Enter here the name of the file you wish to download. If
Enter the IP or IPX address of the server which
This field keeps you informed of the progress of
U T VT100 I
SING HE NTERFACE
DUA1850-0AAA05
