3Com LINKBUILDER 3C18500 User Manual page 23

Product Code
3C18600
3C18620
3C18640
3C18645
The following transceiver modules available to enable connection of a
different media type to some MSH modules.
3C12060
3C12063
3C12064
3C12065
3C12066
As new MSH modules are released by 3Com, or new features are added
to the MSH Management Module, we will release new versions of the
management module code.
If you receive a 3Com module with a disk, the disk will contain new
software which can be downloaded to the management module or
token ring RingBuilder. The disk will also contain the program required
to perform the download from a personal computer.
We recommend that you check the software version on the disk
against the software version on the module. The README file on the
disk contains the information you need. To find out the version of the
image on the module, install the module. When the module has
initialized, use the display panel to access the data (see
Display Panel"
module version, upgrade the new image (see
Management Module System"
DUA1850-0AAA05
Name
4-port Ethernet Bridge
2-port Token Ring Bridge
LinkSwitch 1200 FDDI for MSH Module
LinkSwitch 1200 FDDI for MSH Expansion Module
Male AUI Transceiver Module
TP Transceiver Module
Fan Out Transceiver Module
Fiber Optic Transceiver Module
Coaxial Transceiver Module
on page 4-3). If the disk version is greater than the
on page 5-29).
Overview of the MSH
"Using the
"Upgrading the
2-3
