Token Ring Service

To display the configuration of a token ring or view its soft error
statistics you must select a token ring service at the Chassis Service
menu.
The MSH chassis supports easy identification of services. When you
select a token ring service, the LEDs on the display panel above each
module that forms that service will flash pink/green until you select the
next level menu.
Having selected a token ring service the display will then show a
wrap-around menu offering you the following facilities:
Ring Status.
Ring Configuration.
Ring Statistics.
Ring Station Information.
The following sections explain how to use each facility.
An isolated RingBuilder Module (local ring section number set to zero)
can still be monitored through the display panel. The RingBuilder will be
displayed followed by the number of the slot it occupies in the MSH
chassis.
An isolated MAU module cannot be managed, with the exception that it
can be switched into a local ring section by management command,
for example via VT100 Management. See "Facility Table" on page 11-20.
