Introduction

The figure opposite shows the full menu tree available from the
display panel for repeater management.
The display panel gives you access to data. You have no control
function available from the panel.
The description of the display panel menu given here assumes you
have moved through the menu as far as 'Chassis Service' (see
page
The method of moving through the menu is repeated here for your
convenience.
implies using 'Next' or 'Previous' for moving within one level.
implies using 'Enter' or 'Select' for moving between levels.
You enter the Repeater Management facility by choosing one of the
repeater services, for example: Repeater Backplane 1.
At the level you have reached, the wrap-around menu offers you the
choice of:-
Configuration.
Repeater Statistics.
Module Statistics.
Port Statistics.
The sections below tell you how to follow each path and what you will
find at the end.
