3�4�- DEVICE TERMINALS
3�4�1�- LIST OF TERMINALS, CVM-C10-ITF, CVM-C10-MC AND CVM-C10-mV MODELS
12
Table 4: List of terminals of the CVM-C10-ITF, CVM-C10-MC and CVM-C10-mV�
1 : A1 Auxiliary power supply.
2: A2 Auxiliary power supply.
3: Rc, Common relay output
4: R2, Relay output 2
5: R1, Relay output 1
6: CT, Common digital output.
7: T2, Digital output 2
8: T1, Digital output 1
9: A(+), RS485
10: B(-), RS485
11: GND, for RS485 and digital inputs
12: I1, digital input 1 / tariff selection
2 3 4
1
POWER SUPPLY
V
14 15
Figure 1: Terminals of the CVM-C10-ITF, CVM-C10-MC and CVM-C10-mV�
Device terminals
13: I2, digital input 2 / tariff selection
14: V Voltage input L1
L1,
15: V
L2,
16: V ,Voltage input L3
L3
17: N, Neutral
18: S1 Current input L1
,
19: S2, Current input L1
20: S1, Current input L2
21: S2, Current input L2
22: S1, Current input L3
23: S , Current input L3
2
5 6 7
8
OUTPUTS
S0- S0+ S0+
RS485
A(+) B(-)
Rc R2 R1 Tc T2 T1
Ph-Ph Ph-N
300V ~
520V ~
P1 P2 P1
L1
V V N
L1 L2 L3
S1 S2 S1
16 17 18 19
Voltage input L2
9 10 11 12
13
INPUTS
I1 I2
GND
P2 P1 P2
L2 L3
S2 S1 S2
20 21 22 23
