4�10�3�8�5� Type of installation
Configuration variable
Type of installation
4�10�3�8�6� Maximum demand
Integration period
4�10�3�8�7� Operating profile
Operating profile
4�10�3�8�8� Display backlight
Backlight
4�10�3�8�9� Activating the harmonics display screen
Display of harmonics
80
Table 32: Modbus memory map: Type of installation
Address
2B5C
Table 33: Modbus memory map: Maximum demand
Configuration variable
Table 34: Modbus memory map: Operating profile
Configuration variable
Table 35: Modbus memory map: Backlight
Configuration variable
Table 36: Modbus memory map: Display of harmonics
Configuration variable
Type of installation
Valid data margin
0: Three-phase network with 4 wires�
1: Three-phase network with 3 wires.
2:
Three-phase network with 3 wires, Aron.
3: Two-phase network with 3 wires.
4: Single-phase network with 2 wires, phase-to-
phase.
5:
Single-phase network with 2 wires, phase-to-
neutral.
Maximum demand
Address Valid data margin
274C 1 - 60 minutes
Operating profile
Address Valid data margin
0: Analyzer
1: User
2B60
2: Electrical energy efficiency, e
Backlight
Address Valid data margin
2B5E
5 - 99 seconds
Display of harmonics
Address Valid data margin
2B62
Default
value
Default
3
Default
value
0: Always lit
Default
value
0: No
1: Yes
Instruction Manual
CVM-C10
Default
value
0
15
value
0
0
1
