Deleting energies
Deleting maximum and minimum values
Starting maximum demand
Deleting the hour counters (All tariffs)
Deleting the maximum value of the maximum demand
Deleting energies, maximum demand and maximum and min-
imum values
4�10�3�5� Power status�
All the Modbus map addresses are hexadecimal.
The 0x04 function is implemented for this variable.
This variable indicates the quadrant in which the device is operating.
The variable format is shown in
Bit 7
0
4�10�3�6� The unit's serial number�
All the Modbus map addresses are hexadecimal.
The 0x04 function is implemented for this variable.
Serial number
4�10�3�7� Detection of incorrect direction of rotation (Version 4.05 or higher)
All the Modbus map addresses are hexadecimal.
The 0x04 function is implemented for this variable.
This variable indicates whether an incorrect direction of rotation has been detected in the voltages.
Detection of incorrect direction of rotation
78
Table 23: Modbus memory map: Deleting parameters�
Parameters
Table 24: Modbus memory map: Power status
Power status
Variable
Power status
Table 25:
Table 25: Variable format: Power status�
Bit 6 Bit 5 Bit 4
0 0 0 1: Capacitive
Table 26: Modbus memory map: Serial number�
Variable
Table 27: Modbus memory map : Detection of incorrect direction of rotation�
Detection of incorrect direction of rotation
Variable
Address
834
838
839
83D
83F
848
Address
7D1
Bit 3 Bit 2
1: Inductive
The unit's serial number
Address
578 - 579
Address
7D5
Valid data margin
FF00
FF00
FF00
FF00
FF00
FF00
Default value
-
Bit 1 Bit 0
1: Generated 1: Consumed
Default value
-
Value
0: No fault has been detected
1: Fault detected
