Bit 7
0
4�10�3�8�16� Communications
Configuration variable
Protocol
Modbus and BACnet: Peripheral number
Modbus : Transmission speed
Modbus : Parity
Modbus : Data bits
Modbus : Stop bits
BACnet: Device ID
BAcnet: MAC
4�10�3�8�17� Password configuration
These variables allow you to lock or unlock access to the programming menu, and also allow you to
change the password code. The password code may only be changed through this command.
The device does not need you to enter the old password in order for it to record the new one; it records
the new one directly without any verification.
Password
Configuration variable
Password value
(13)
Lock-Unlock
You must program all the variables at the same time.
(12)
The password value is read and written in hexadecimal.
(13)
Instruction Manual
Table 45: Variable format: Status of the digital outputs�
Bit 6 Bit 5 Bit 4 Bit 3
Output 4
0 0 0 0: OFF
1: ON
Table 46: Modbus memory map: Communications
Communications
Table 47: Modbus memory map: Password configuration
Address
(12)
2B70
2B71
Bit 2 Bit 1
Output 3 Output 2
0: OFF 0: OFF
1: ON 1: ON
Address Valid data margin
0 : Modbus
2742
1: Bacnet
2743 0 - 255
2744 0: 9600 - 1:19200
0: No parity
1: Odd parity
2745
2: Even parity
0 : 8 bits
2746
1: 7 bits
0 : 1 stop bit
2747
1: 2 stop bits
0- 999999
2EE0- 2EE1
2EE2 0- 255
Valid data margin
0 - 9999
0: Unlock
1: Lock
Bit 0
Output 1
0: OFF
1: ON
Default
value
0
1
0
0
0
0
-
2
Default value
1234
0
