3�4�2�- LIST OF TERMINALS, CVM-C10-ITF-IN AND CVM-C10-MC-IN MODELS�
1 : A1 Auxiliary power supply.
2: A2 Auxiliary power supply.
3: Rc, Common relay output
4: R2, Relay output 2
5: R1, Relay output 1
6: S2, Neutral current input
7: S1, Neutral current input
8: A(+), RS485
9: B(-), RS485
10: GND, for RS485 and digital inputs
11: I1, digital input 1 / tariff selection
1
Instruction Manual
Table 5: List of terminals of the CVM-C10-ITF-IN and CVM-C10-MC-IN�
Device terminals
6
2 3 4 5
OUTPUTS
POWER SUPPLY
Rc R2 R1
P2
Ph-Ph Ph-N
300V ~
520V ~
V V V
L1 L2 L3
13 14 15 16
Figure 2: Terminals of the CVM-C10-ITF-IN and CVM-C10-MC-IN�
12: I2, digital input 2 / tariff selection
13: V
Voltage input L1
L1,
14: V
Voltage input L2
L2,
15: V ,Voltage input L3
L3
16: N, Neutral
17: S1 Current input L1
,
18: S2, Current input L1
19: S1, Current input L2
20: S2, Current input L2
21: S1, Current input L3
22: S , Current input L3
2
7
8 9 10 11
RS485 INPUTS
A(+) B(-) I1 I2
S2
S1
LN
GND
P1
P1 P2 P1 P2 P1 P2
L1 L2 L3
N
S1 S2 S1 S2 S1 S2
17 18 19 20
12
21 22
13
