3�5�16�- MEASURING SINGLE-PHASE NETWORKS, PHASE TO NEUTRAL, WITH A 2-WIRE CONNEC-
TION, CVM-C10-FLEX MODEL�
Figure 19: Measuring Single-Phase Networks, phase to neutral, with a 2-wire connection, CVM-C10-FLEX model�
30
Measurement system:
V N
L1
a b
A B
L1
N
It is mandatory connect the SHLD terminal of the probe.
POWER SUPPLY
Ph-Ph Ph-N
300V ~
520V ~
V V V
L1 L2 L3
V N
L1
LOAD
Power
Supply
RS485 INPUTS
A(+) B(-) I1 I2
GND
FLEX-MAG (100mV~ )
N
L1 L2 L3 LN C SHLD
L1
C
SHLD
